HYDRAULIC
FORESTRY WINCH
Pulling Capacity
8.5 Tons
Maximum Rope Length
120 m / Ø 12 mm
Weight (Without Rope)
530 kg
Your tools will always be ready for use.
Two-Sided Chain Hanging and Storage Boxes
.jpg)
Foldable window guard for easy transportation.
Maintains the wire rope between the unwinding pulley and drum under constant tension. Also, the Automatic Stop Switch automatically stops the winding function of the wire rope on the drum.
Lockable safety pin keeps the rope on top.
Bolted easy to remove trailer carrier.
Two different pin diameters and connection heights suitable for your tractor.
Provides high quality, friction-resistant and safe fastening.
| Pulling Capacity | 8.5 Tons |
| Brake Capacity | 10.6 Tons |
| Average Winch Speed | 0.6 m/s |
| Standard Rope Length | 90 m / Ø 13 mm |
| Maximum Rope Length | 120 m / Ø 12 mm 100 m / Ø 13 mm |
| Recommended Tractor Power | >59 kW / >80 HP |
| Control | Electro Hydraulic |
| Number of Clutch Plates | 3 |
| Width | 1840 mm * 2040 mm |
| Depth | 650 mm |
| Unprotected Wire Height | 1750 mm |
| Protected Wire Height | 2300 mm |
| Weight (Without Rope) | 530 kg * 590 kg |
| Mounting Category | II, III |
| Radio Remote Control | Standard |
| Rope Unwinding System | Standard |
| Wire Rope Continuous Unwinding Speed Valve | Standard |
| Bottom Pulley | Standard |
| Trailer Connection | Standard |
| Motorsaw Holder | Standard |
